Technical Specification
System
Main Processor
Embedded microprocessor
Operating System
Embedded LINUX
Audio and Video
IP Camera Input
4 Channel
Two-way Talk
1 Channel Input, 1 Channel Output, RCA
Display
Interface
1 HDMI, 1 VGA, 2 TV
Resolution
1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split
1/4
Privacy Masking
4 rectangular zones (each camera)
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression
H.264/G.711/PCM
Record Rate
Max 200 Mbps
Bit Rate
48~8192Kb/s
Record Mode
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips
Video Detection
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm input
8 channel
Relay Output
2 channel
Playback and Backup
Playback
1/4
Search Mode
Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode
USB Device/Network
Storage
Internal HDD
2 SATA Ports, Up to 4 TB capacity
SD card
1 SD card, Up to 128 GB
Network
Ethernet
RJ-45 Port (10/100/1000Mbps)
PoE Port
4 ports(IEEE802.3af/at)
Wireless Network
Built-in 3G/4G/Wi-Fi module(optional)
GPS
Built-in high accurate GPS module(optional)
Network Function
TCP/IP, UDP, DHCP, DDNS, FTP, Email, Alarm Server
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android
Auxiliary Interface
USB
2 Ports (1 rear), USB 3.0
RS232
1 Port, for PC Communication and Keyboard
RS485
1 Port, for PTZ Control
CAN
Support
Heater
Optional
G-sensor
Support
Electrical
Power Supply
DC 6V~36V
Power Consumption
<15W (Without HDD)
Environmental
Operating Conditions
-30°C (with heater)~ +60°C (+14°F ~ +131°F)
Storage Conditions
-30°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions
180mm×208mm×100mm (7.1″ x 8.2″ x 3.9″)
Net Weight
3kg (6.6 lb) (without HDD)
Certifications
CE
FCC
EN50155
ISO16750
E-mark
