- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
- Day & NightICR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Slow ShutterMax. 16 times
- Light AlarmYes
- Lens
- Lens Type2.8 mm, 3.6 mm fixed lens
- Focal Length & FOV103.5° (2.8 mm), 82.6° (3.6 mm)
- Lens MountM12
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Mirror, Smart IR
- Frame RatePAL: 1080p@25fps,NTSC: 1080p@30fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)≥130 dB
- Image EnhancementWDR/BLC/HLC/Global
- Privacy Mask4 programmable privacy masks
- Noise Reduction3D DNR
- White BalanceAuto/Manual
- White LightAuto/Off
- AGCYes
- Supplement Detection(PIR)
- PIR RangeAngle: 110°
- Interface
- Video OutputTVI only
- Event
- Motion Detection4 programmable motion areas
- General
- MaterialMetal
- Dimension68 mm × 70 mm × 179.8 mm (2.68″ × 2.76″ × 7.08″)
- WeightApprox. 345 g (0.76 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply12 VDC ± 25%,*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 4.5 W
- IR RangeUp to 30 m
- White Light RangeUp to 20 m
- Approval
- ProtectionIP67
