- General
- Core Color1 White- Blue /Blue 2 White-Orange /Orange,3 White- Green /Green 4 White- Brown /Brown,
- PackingWooden Tray & Carton
- Carton DimensionPer request
- Packing Length(305±1.5)m
- Rip-CordYes
- Drain WireNo
- Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×10d,After Aging Tensile Strength(Mpa) ≥12.5, Elongation(%) ≥125,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
- Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,1.0-100.0MHz Delay Skew (ns/100m) ≤45,DC ResistanceΩ/100m) max 9.5,DC Conductor Resistance Unbalance(%) max 5.0,
- Conductor
- MaterialSolid-Bare Copper,Content 99.95%,
- Nom.O.D.(Mm)0.500±0.005
- Insulation
- MaterialHDPE
- Diameter0.88±0.04mm
- Sheath
- Thickness0.50±0.05 mm
- External O.D.5.0±0.4 mm
- SurfaceClean,Frap,Satiation
- MaterialPVC(complies RoHS),CM
- ColorGrey ZLC1003
- Surface Printing
- Letter Height3.0±0.3mm
- ColorBlack
- Print Error & Space≤±0.5%，1m
