HIKVISION 32-CH 5MP 1.5U H.265 ACUSENSE DIGITAL VIDEO RECORDER (iDS-7332HUHI-M4/S)

₱82,240.00

Deep learning-based perimeter protection
Deep learning-based motion detection 2.0 for all analog channels
Up to 32-ch analog camera inputs and 4 SATA interfaces
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression
Up to 8 MP@8 fps/5 MP@12 fps encoding capability
HDTVI/AHD/CVI/CVBS/IP video inputs
POS triggered recording and POS information overlay
Up to 64-ch network camera inputs

SKU: HIKVISION 32-CH 5MP 1.5U H.265 ACUSENSE DIGITAL VIDEO RECORDER (iDS-7332HUHI-M4/S) Categories: Hikvision, Hikvision 32CH, Hikvision Digital and Network Video Recorders Tag: HIKVISION 32-CH 5MP 1.5U H.265 ACUSENSE DIGITAL VIDEO RECORDER (iDS-7332HUHI-M4/S)

Description

- Motion Detection 2.0
- Human/Vehicle Analysis
  Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
  Quick search by object or event type is supported;
- Perimeter Protection
- Human/Vehicle AnalysisUp to 16-ch, for channel 1/2/3/4/9/10/11/12/17/18/19/20/25/26/27/28 only
- Recording
- Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding Resolution8 MP/3K/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
- Frame Rate
  Main stream:
  8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/3 MP@18 fps
  1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
  Sub-stream:
  WD1/4CIF/CIF@25 fps (P)/30 fps (N)
- Video Bitrate32 Kbps to 10 Mbps
- Dual-StreamSupport
- Stream TypeVideo, Video & Audio
- Audio CompressionG.711u
- Audio Bitrate64 Kbps
- Video And Audio
- IP Video Input
  32-ch (up to 64-ch);
  Up to 12 MP resolution;
  Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog Video Input
  32-ch;
  BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Incoming Bandwidth320 Mbps
- Outgoing Bandwidth256Mbps
- HDTVI Input8 MP, 3K, 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
- AHD Input5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS InputPAL/NTSC
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- HDMI 1 Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI 2 Output1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Video Output ModeHDMI1/VGA simultaneous output, HDMI2/VGA independent output
- Audio Input4-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent)
- Synchronous Playback16-ch
- VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Network
- Remote Connection128
- Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP
- Network Interface2, RJ45 10M/100M/1000M self-adaptive Ethernet interface
- Auxiliary Interface
- SATA4 SATA interfaces
- ESATASupport
- CapacityUp to 12 TB capacity for each disk
- Serial InterfaceRS-232, RS-485 (full-duplex), Keyboard
- Alarm In/Out16/4
- USB InterfaceFront panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0
- General
- Power Supply100 to 240 VAC, 50 to 60 Hz
- Consumption≤ 55 W (without HDD)
- Working Temperature-10 °C to +55 °C (+14 °F to +131 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)445 × 400 × 71 mm (17.5 × 15.7 × 2.8 inch)
- Weight≤ 7 kg (without HDD, 15.4 lb.)
