- Camera
- Image Sensor1/1.8″ 3K CMOS
- Signal SystemPAL/NTSC
- Max. Resolution2960 (H) × 1665 (V)
- Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Light AlarmSolid Light Alarm (White Light)
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Lens
- Lens Type2.8 mm and 3.6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 112°, vertical FOV: 60°, diagonal FOV: 133°
3.6 mm, horizontal FOV: 95°, vertical FOV: 50°, diagonal FOV: 115°
- Lens MountM16
- Image
- Frame Rate3K@20fps, 4MP@25fps/30fps, 1080p@25fps/30fps
- Wide Dynamic Range (WDR)≥130 dB
- White LightAuto/Off
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- AGCYes
- Day/Night ModeColor
- White BalanceAuto/Outdoor/Global/Manual
- Image EnhancementWDR;Global;HLC;BLC;HLS
- Privacy Mask4 programmable privacy masks
- Noise Reduction3D DNR/2D DNR
- Image SettingsBrightness;Contrast;Mirror;Smart Light;Anti-Banding
- Interface
- Video Output1 HD analog output
- Event
- Motion Detection4 programmable motion areas
- General
- LanguageEnglish
- Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply
12 VDC ± 25%
*You are recommended to use one power adapter for one camera, and use 2-pin power supply for long-distance power supply.
- ConsumptionMax. 4 W
- MaterialMetal
- White Light RangeUp to 20 m
- CommunicationHIKVISION-C
- Dimension161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
- WeightApprox. 400 g (0.88 lb.)
- Approval
- ProtectionIP67
