- Camera
- Image Sensor5 MP CMOS image sensor
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 340°; Tilt: 0° to 75°; Rotate: 0° to 355°
- Lens
- Lens Type2.7 mm to 13.5 mm motorized vari-focal lens
- Focal Length & FOV95.7° to 29.1°
- Lens MountΦ 14
- Image
- Image SettingsBrightness, Sharpness, DNR, Mirror, Smart IR
- Frame RatePAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)DWDR
- Image EnhancementBLC
- White BalanceATW/MWB
- AGCSupport
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialPlastic
- DimensionØ 136 mm × 101.9 mm ( Ø 5.35″ × 4.01″)
- WeightDS-2CE56H0T-ITZF: 410 g (0.90 lb.),DS-2CE56H0T-AITZF: 445 g (0.98 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- Power Supply12 VDC ±15%, 24 VAC ±15%
- ConsumptionDS-2CE56H0T-ITZF: Max. 4.4 W,DS-2CE56H0T-AITZF: Max. 6.0 W
- IR RangeUp to 40 m
