WIRELESS Standards Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz (1)
IEEE 802.11ax/ac/n/a 5 GHz (2)
IEEE 802.11ax/n/b/g 2.4 GHzWiFi Speeds AX7800
5 GHz (1): 4804 Mbps (802.11ax, HE160)
5 GHz (2): 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax)WiFi Range 4-6+ Bedroom Houses (2-pack)
1-3 Bedroom Houses (1-pack)TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverageAI-Driven Mesh
Intelligently learns the network environment to provide ideal WiFi unique to your home4× High-Gain Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas2× Smart Antennas (Internal)
Smart antennas auto-detect other Deco units to establish a stronger backhaul between one another to boost WiFi coverageTri-Band
Provides an extra 5 GHz band working exclusively as the strong backhaul, strengthening the WiFi coverageBeamforming
Concentrates wireless signal strength towards clients to expand WiFi rangeWiFi Capacity Very High Tri-Band
Distribute devices to different bands for optimal performance4×4 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clientsOFDMA
Simultaneously communicates with multiple WiFi 6 clients8 Streams
More than enough bandwidth for connected devicesWorking Modes Router Mode
Access Point ModeSECURITY Network Security SPI Firewall
Access ControlHomeShield SecurityReal-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network ScannerGuest Network 1× 5 GHz Guest Network
1× 2.4 GHz Guest NetworkWiFi Encryption WPA-Personal
WPA2-Personal
WPA3-PersonalHARDWARE Ethernet Ports 1× 2.5 Gbps port + 2× Gigabit ports *Per Deco Unit
Supports WAN/LAN auto-sensingButtons Reset Button SOFTWARE Protocols IPv4
IPv6Service Kits HomeShield
Learn More>Parental Controls HomeShield Parental Controls Youtube Restriction
SafeSearch
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly ReportsWAN Types Dynamic IP
Static IP
PPPoE
PPTP
L2TPQuality of Service HomeShield QoS QoS by Device
Cloud Service OTA Firmware Upgrade
TP-Link ID
DDNSNAT Forwarding Port Forwarding
UPnPIPTV IGMP Proxy
IGMP Snooping
Bridge
Tag VLANDHCP Address Reservation
DHCP Client List
ServerDDNS TP-Link Management Deco App TEST DATA WiFi Transmission Power CE:
<20 dBm (2.4 GHz)
<30 dBm (5 GHz)FCC:
<30 dBm(2.4 GHz)
<30 dBm(5 GHz)PHYSICAL Dimensions (W×D×H) 5.1 × 4.8 × 8.3 in
(130 × 123 × 210.5 mm)
